When the board receives the Laser Beam from the Laser Gun, the Photodiode gets activated and it will turn ON the transistor T1 so that the LED –LT1 DETECT will be in ON state. Main Board: The Main Board part resides in the Photodiode Receiver section. An ON/OFF switch is connected with the battery and when the switch is in ON position, the three LEDs will be ON to indicate that the power is switched ON. Power Section: A 9 Volt battery is used here. The sections included in the Laser Gun DIY Electronics Projects are – Power section, Main Board, Gun Trigger Board and the Relay Board. The circuit diagram along with PCB and Component Layout of Laser Gun is shown in the figure below.
Circuit Diagram explanation of Cool Shooting Games Using laser Gun: Note that the Photodiode Receiver section will activate only when the transmitted Laser beam comes in line of sight with the photodiode and it will be indicated by another RED LED.īlood indicating LED: When the light Beam from the Laser Gun hits the correct position of the Photodiode, then only the Blood Indicating LED will be made ON. Here we are using an indicating LED in the photodiode Receiver section to indicate that the Photo Diode section is ON during night. Photodiode Receiver: Photo Diode Receiver Section, receives the transmitted Laser beam from the Laser Gun and provides the necessary actions. You can use any of the available Laser Torch/Gun for your project. Also the Laser torch/Gun can be easily available in the market with low cost. They provide a wide range up to 500 meters. We can use simple Laser Torch as the Laser Gun. Laser Gun: This is the heart of this DIY Electronics project. The major parts included in the Cool Shooting Games Using laser Gun DIY Electronics Projects are, Block Diagram of Cool Shooting Games Using laser Gun: With this DIY Project you can play shooting games like in the films with friends. Here we are discussing about a simple DIY Electronics Project - Cool Shooting Games using laser Gun.
So why don’t you think to make a Cool Shooting Games Using laser Gun like that the hero used in the films? Yes!!! Now it is possible with this interesting DIY Electronics project. It’s very interesting to watch that films or shows. You may have noticed in Science fiction films or Shows like “Star Trek” and “Star Wars” that uses Laser Guns and Weapons in the fictional battles. This Cool Shooting Games Using laser Gun DIY Electronics Project is mainly for Gaming Actions.
